VISOR
®
Communications manual
Read detector list (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Read detector list (binary) request string to sensor
Byte no. Data type Content Meaning
1 - 4
Unsigned
Int
0x05 Telegram length
5
Unsigned
Char
0x15 Get Detector List
Read detector list (binary) response string from sensor
Byte no. Data type Content Meaning
1 - 4
Unsigned
Int
0xXX Telegram length
5
Unsigned
Char
0x18 Get Detector List
6
Unsigned
Short
0xXX Error codes (Page 88)
8
Unsigned
Char
0xXX Job number of current job
9
Unsigned
Char
0xXX Number of detectors in the current job
NOTE:
The following byte sequence is repeated for each detector in the
job. The byte numbers shift accordingly.
10
Unsigned
Char
0xXX
Number of subsequent bytes. This allows a unique
name for the detector n to be specified.
11 ... n
Unsigned
Char
0xXX
From this position, the name for detector n follows,
in the given length.
n + 1 ... n
+ 3
Unsigned
Char
0xXX
001 - Pattern matching
004 - Contour comparison
005 - Grayscale
006 - Contrast
06814859 - 1/24/2019-00 Page 220 EN
