VISOR
®
Communications manual
Get image (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Get image (ASCII) request string to sensor
Byte no. Content Meaning
1 G
Get Image2 I
3 M
4 X
0 - Last image
1 - Last poor image
2 - Last good image
Example: GIM1
Get image (ASCII) response string from sensor
Byte no. Content Meaning
1 G
Get Image2 I
3 M
4
P
F
P successful (Pass)
F Fail
5 X Error codes (Page 88)
6 X
Image type
0 - Grayscale
3 - Bayer Pattern_BG
When converting the color image from Bayer into RGB, the
appropriate image type must be considered.
Pre-processing filters of the category "Arrangement" have an
influence on the Bayer type. Bayer Pattern begins with blue - green.
7 X
Image result
1 - Good image
Page 159 EN 06814859 - 1/24/2019-00
