Calibration: Copy calibration (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Calibration: Copy calibration (binary) request string to sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0x09 Telegram length
5
Unsigned
Char
0x25 Calibration: Copy Calibration
6
Unsigned
Char
0x01 Request version
7
Unsigned
Char
0x01 Constant
8
Unsigned
Char
0xXX
Destination
0 : Copy to all jobs
>0: Copy to specified job
9
Unsigned
Char
0xXX
0: Always copy when the calibration is active.
1: Only copy if the calibration method is the
same.
Calibration: Copy calibration (binary) response string from sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0x08 Telegram length
5
Unsigned
Char
0x25 Calibration: Copy Calibration
6 - 7
Unsigned
Short
0xXX Error codes (Page 88)
8
Unsigned
Char
0xXX
00: Successful
>0 : Job number at which the error occurs.
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
