Auto operating distance (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Auto operating distance (binary) request string to sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0x08 Telegram length
5
Unsigned
Char
0x32 Auto Focus
6
Unsigned
Char
0xX1 Request version
7
Unsigned
Char
0xXX
Unit
0 - 1/1000 millimeters
4 - steps
8
Unsigned
Char
0xXX
Operating distance selection
0 - False
1 - True
NOTE:
The following byte sequence is only relevant if "Operating
distance selection" has been set to 1.
9
Unsigned
Char
0xXX
Operating distance
0 - Maximum score
1 - Min. Operating distance
2 - Max. operating distance
3 - Operating distance average
4 - Operating distance median
5 - Maximum score and all planes
10
Unsigned
Char
0xXX
Distance range selection
0 - False
1 - True
NOTE:
The following byte sequence is only relevant if "Distance range
selection" has been set to 1.
11 Int 0xXX Close distance
