VISOR
®
Communications manual
Calibration: Set parameter (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Calibration: Set parameter (ASCII) request string to sensor
Byte no. Content Meaning
1 C
Calibration: Set Parameter2 S
3 P
4 1 Request version
5 X
0: Temporary
1: Permanent
6 - 8 X Parameter number (Page 154)
9 - 16 X Length of the following data
17 ... n X Parameter value
Example: CSP11002000000019
Calibration: Set parameter (ASCII) response string from sensor
Byte no. Content Meaning
1 C
Calibration: Set Parameter2 S
3 P
4
P
F
P successful (Pass)
F Fail
5 - 7 X Error codes (Page 88)
Example: CSPP000
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Page 153 EN 06814859 - 1/24/2019-00
