VISOR
®
Communications manual
Extended trigger (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Extended trigger (ASCII) request string to sensor
Byte no. Content Meaning
1 T
Extended trigger, (trigger
with index, for correlation of
trigger to corresponding
result data, via port 2006)
2 R
3 X
4 - 5 X Length of following data (n)
6 ... n X Data
Example: TRX06MyPart
Extended trigger (ASCII) response string from sensor
Byte no. Content Meaning
1 T
Extended trigger,
(response to trigger with
index and result data, via
port 2006, for correlation of
trigger to corresponding
result. Result data without
index via port 2005)
2 R
3 X
4
P
F
P successful (Pass)
F Fail
5 - 6 X Length of following data (n)
7 ... n X Data of sending command
n+1
C
R
C = Config
R = Run
n+2 ... n+9 X
Length of following result
data (n)
n+9 ... m X Result data
Page 93 EN 06814859 - 1/24/2019-00
