Sensopart Visor - Unsigned Int

VISOR
®
Communications manual
02= Rectangle
03= Ellipse
04= Free shape
15 - 18 Unsigned Int 0xXX ROI parameter: Center X (value in pixels * 1000)
19 - 22 Unsigned Int 0xXX ROI parameter: Center Y (value in pixels * 1000)
23 -26 Unsigned Int 0xXX
ROI parameter: Half width / radius X (value in pixels
* 1000)
Only for ellipse / rectangle:
27 - 30 Unsigned Int 0xXX
ROI parameter: Half width / radius Y (value in pixels
* 1000)
31 - 34 Unsigned Int 0xXX ROI parameter: Angle in ° (value in ° * 1000)
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is low: Yes
Status of Ready signal during
processing:
Low
Supported interfaces:
Telegrams: Availability and supported interfaces
(Page 85)
Page 217 EN 06814859 - 1/24/2019-00
