VISOR
®
Communications manual
Extended trigger (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Extended trigger (binary), request string to sensor
Byte
no.
Data type Content Meaning
1 - 4
Unsigned
Int
0xXX Telegram length
5
Unsigned
Char
0x13
Extended trigger command, trigger with index, for assigning
triggers to corresponding result data, via port 2006)
6
Unsigned
Char
0xXX Length of following data (n)
7 ...
n
Unsigned
Char
0xXX Data
Extended trigger (binary) response string from sensor
Byte
no.
Data type Content Meaning
1 - 4
Unsigned
Int
0xXX Telegram length
5
Unsigned
Char
0x13
Extended Trigger command, (response to trigger with index and
result data, via port 2006, for correlation of trigger to
corresponding result, Result data without index, via port 2005
also)
6 - 7
Unsigned
Short
0xXX Error codes (Page 88)
8
Unsigned
Char
0xXX Length of following data (n)
9 ...
n
Unsigned
Char
0xXX Data of sending command
n+1
Unsigned
Char
0xXX
Operating mode
0 = Config mode
1 = Run mode
Page 191 EN 06814859 - 1/24/2019-00
