VISOR
®
Communications manual
Update visualization data (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Update visualization data (ASCII) request string to sensor
Byte no. Content Meaning
1 U
Update Visualization Results2 V
3 R
4 1 Request version
5 X
Image:
0 - No image is being created
1 - Gray value image /RGB image is being created
2 - Gray value image /Bayerpattern is being
created
6 X
Result XML:
0 - Result file will be not be created
1 - Result file is being created
7 X
Statistic XML:
0 - Statistic file will not be created
1 - Statistic file is being created
8 X
Image type:
0 - Last image (Any)
1 - Last fail image (Fail)
2 - Last pass image (Pass)
3 - Next image (Any)
4 - Next fail image (Fail)
5 - Next pass image (Pass)
9 - 11 X
Directory number
000: visu000
Example: UVR11110000
Update visualization data (ASCII) response string from sensor
Byte no. Content Meaning
Page 161 EN 06814859 - 1/24/2019-00
