VISOR
®
Communications manual
1 U
Update Visualization Results2 V
3 R
4
P
F
P successful (Pass)
F Fail
5 - 7 X Error codes (Page 88)
8 X
Data available:
0: New data available when ready.txt is written
1: No new data available.
9 - 11 X
Directory number
000: visu000
Example: UVRP0000000
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is low: Yes
Status of Ready signal during
processing:
No change
Supported interfaces:
Telegrams: Availability and supported interfaces
(Page 85)
End of telegram: Max. 4 bytes (optional)
The created files are available for download in the directory /tmp/[Directory number]:
l image.bmp
l overlay.xml
With the file "overlay.xml", all relevant information for creating the overlay can be obtained. The
file is created in XML format. The most important elements are described in the table below
Name Value Description
detector type
pattern_matching
contour
contrast
Detector type
