VISOR
®
Communications manual
Read detector list (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Read detector list (ASCII) request string to sensor
Byte no. Content Meaning
1 G
Get Detector List2 D
3 L
Example: GDL
Read detector list (ASCII) response string from sensor
Byte no. Content Meaning
1 G
Get Detector List2 D
3 L
4
P
F
P successful (Pass)
F Fail
5 - 7 X Job number of the current job
8 - 10 X Number of detectors in the current job
NOTE:
The following byte sequence is repeated for each detector in the
job. The byte numbers shift accordingly.
11 - 13 X
Number of subsequent bytes. This allows a unique name
for the detector n to be specified.
14 ... n X
From this position, the name for detector n follows, in the
given length.
n + 1 ... n+ 5 X
001 - Pattern matching
004 - Contour comparison
005 - Grayscale
006 - Contrast
06814859 - 1/24/2019-00 Page 130 EN
