VISOR
®
Communications manual
2.4 Used Ethernet - Ports
If you are integrating the VISOR
®
into a network, make sure that an admin opens the following
ports if necessary. This is only the case if these ports were previously explicitly blocked in the
company network or by a firewall installed on the PC.
The following ports are used for communications between the VISOR
®
Software (PC) and the
VISOR
®
vision sensor:
l Port 2000, TCP
l Port 2001, UDP Broadcast (to find sensors via SensoFind)
l Port 2002, TCP
l Port 2003, TCP
l Port 2004, TCP
he following ports are used for communications between the PLC (PLC or control PC) and
VISOR
®
.
Process interfaces:
l Ethernet
l Port 2005, TCP (Implicit results, i.e. user-configured result data)
l Port 2006, TCP (Explicit requests, e.g. trigger or job switch)
l EtherNet/IP:
l Port 2222, UDP
l Port 44818, TCP
l PROFINET:
l Port 161, UDP
l Port 34962, UDP
l Port 34963, UDP
l Port 34964, UDP
l Service:
l Port 1998
l SensoWeb:
l Port 80
NOTE:
If Ports 2005 or 2006 are changed in the configuration software, they must also be
changed accordingly in the firewall by an administrator.
Page 10 EN 06814859 - 1/24/2019-00
