VISOR
®
Communications manual
Table of contents
1 Information on this document 5
1.1 What the symbols mean 5
1.2 Additional documents 6
2 Network connection 7
2.1 Integrating the VISOR® into the network / gateway 7
2.2 Network connection, procedure / Troubleshooting - Direct connection 8
2.3 Network connection, procedure / Troubleshooting - Network connection 9
2.4 Used Ethernet - Ports 10
2.5 Access to VISOR® through network 11
2.6 Access to VISOR® through the Internet / World Wide Web 12
2.7 VISOR® electrical connection on the network 13
3 VISOR® configuration 15
4 Ethernet TCP/IP, port 2005 / 2006 19
4.1 Example: Data output from VISOR® to PC / PLC 19
4.2 Example: Commands (requests) from PC / PLC to VISOR® 24
4.3 Example: Job change from PC / PLC to VISOR® 26
4.4 Example Beckhoff CX 1020 29
4.5 Example Siemens S7 29
5 Service / Visualization 30
5.1 Backup creation 30
5.2 Visualization 30
6 VISOR® telegrams for PROFINET and EtherNet/IP 31
6.1 Module 1: "Control" (from controller to VISOR®) 31
6.2 Module 2: "Status" (from VISOR® to controller) 32
6.3 Module 3: "Data" (from VISOR® to controller) 34
6.4 Module 4: "Request" (from controller to VISOR®) 34
6.5 Module 5: "Response" (from controller to VISOR®) 35
6.6 Start / end criteria for each telegram 35
7 Timing diagrams for VISOR® communication 36
8 Request sequences 42
9 PROFINET 49
9.1 Siemens S7-1200 TIA 12 configuration example 49
9.1.1 Create new project 49
9.1.2 Selecting the GSD file 49
9.1.3 Adding the VISOR® to the project 50
9.1.4 Writing a name to VISOR® 56
9.1.5 Load the project onto the PLC 57
9.1.6 Mapping of output data 57
9.2 PLC example programs 60
