VISOR
®
Communications manual
Set gain (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Set gain (ASCII) request string to sensor
Byte no. Content Meaning
1 S
Set Gain2 G
3 A
4
0
1
0: Temporary
1: Permanent
Permanent change affect all parameters, including those that
were previously only changed temporarily.
5 - 9 X New gain value (in value * 1000), e.g. 2.0 = 02000
Example: SGA102000
Set gain (ASCII) response string from sensor
Byte no. Content Meaning
1 S
Set Gain2 G
3 A
4
P
F
P successful (Pass)
F Fail
5 - 9 X Current gain value
Example: SGAP02000
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is
Yes
Page 113 EN 06814859 - 1/24/2019-00
