VISOR
®
Communications manual
Calibration: Copy calibration (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Calibration: Copy calibration (ASCII) request string to sensor
Byte no. Content Meaning
1 C
Calibration: Copy Calibration2 C
3 C
4 1 Request version
5 1 Constant
6 - 8 X
Destination
0 : Copy to all jobs
>0: Copy to specified job
9 X
0: Always copy when the calibration is active.
1: Only copy if the calibration method is the same.
Example: CCC110021
Calibration: Copy calibration (ASCII) response string from sensor
Byte no. Content Meaning
1 C
Calibration: Copy Calibration2 C
3 C
4
P
F
P successful (Pass)
F Fail
5 - 7 X Error codes (Page 88)
8 - 10 X
Job number of the job where the error occurred
00 - Successful
>0 - Job number of the job where the error first
occurred
Page 151 EN 06814859 - 1/24/2019-00
