VISOR
®
Communications manual
Get image (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Get image (binary) request string to sensor
Byte
no.
Data type Content Meaning
1 - 4
Unsigned
Int
0x06 Telegram length
5
Unsigned
Char
0x03 Get image
6
Unsigned
Char
0xXX
0 - Last image
1 – Last failed image
2 – Last good image
Get image (binary) response string from sensor
Byte
no.
Data type Content Meaning
1 - 4
Unsigned
Int
0xXX
Telegram length
e.g. 00 04 B0 0D (Dez. 307213)
5
Unsigned
Char
0x03 Get image
6 - 7
Unsigned
Short
0xXX Error codes (Page 88)
8
Unsigned
Char
0xXX
Image type
0 - Grayscale
3 - Bayer Pattern_BG
When converting the color image from Bayer into RGB, the
appropriate image type must be considered.
9
Unsigned
Char
0xXX
Image result
00 - Failed image
01 - Good image
10 - 11
Unsigned
0xXX Number of rows
06814859 - 1/24/2019-00 Page 246 EN
