Communications manual
Short e.g. 01 E0 = 480
12 - 13
Unsigned
Short
0xXX
Number of columns
e.g. 02 80 = 640
14 ... n
Unsigned
Char
0xXX Binary image data (rows * columns)
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is low: Yes
Status of Ready signal during
processing:
Low
Supported interfaces: Telegrams: Availability and supported interfaces (Page 85)
