Calibration: Calibrate plate (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Calibration: Calibrate plate (ASCII) request string to sensor
Byte no. Content Meaning
1 C
Calibration: Calibrate by Plate2 C
3 P
4 1 Request version
5 X
0: Temporary
1: Permanent
Permanent change affect all parameters,
including those that were previously only
changed temporarily.
6 X
0: No fiducials are used. The origin of the
measurement coordinate system is identical to
the origin of the calibration coordinate system.
1: No fiducials are used. Measurement
coordinate system is identical to device
coordinate system.
2: Uses world system, fiducial job
3: Uses world system, fiducial command CAW
7 X
0: Calibration internal and external sensor
parameters
1: Validation of calibration
2: Calibration internal sensor parameters
5: Calibration transformation measurement
coordinate system
Example: CCP1110
Calibration: Calibrate plate (ASCII) response string from sensor
Byte no. Content Meaning
