VISOR
®
Communications manual
1 C
Calibration: Calibrate by Plate2 C
3 P
4
P
F
P successful (Pass)
F Fail
5 - 7 X Error codes (Page 88)
8 - 12 X Current number of detected calibration points
13 - 20 X
Deviation calibration, RMSE (root mean square
error)
21 - 28 X Deviation calibration, mean
29 - 36 X Deviation calibration, max.
37 - 44 X Deviation calibration, min.
45 - 52 X X delta (in user unit * 1000)
53 - 60 X Y delta (in user unit * 1000)
61 - 68 0 Reserved
69 - 76 0 Reserved
77 - 84 0 Reserved
85 - 92 X Delta Gamma (in degrees *1000)
93 - 100 X Deviation fiducials, mean
101 - 108 X Deviation fiducials, max.
109 - 116 X Deviation fiducials, min.
Example:
CCPP00000012000010010000200200003003000040040
00050050000600600007007000080080000900900001001
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Page 147 EN 06814859 - 1/24/2019-00
