VISOR
®
Communications manual
Trigger (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Trigger (binary) request string to sensor
Byte
no.
Data type Content Meaning
1 - 4
Unsigned
Int
0x05 Telegram length
5
Unsigned
Char
0x01
Trigger, (simple trigger without index, via
port 2006)
Trigger (binary) response string from sensor
Byte
no.
Data type Content Meaning
1 - 4
Unsigned
Int
0x07 Telegram length
5
Unsigned
Char
0x01
Trigger, (response to trigger command
without index, via port 2006. If defined:
Result data without index via port 2005)
6 - 7
Unsigned
Short
0xXX Error codes (Page 88)
Additional information:
Accepted in run mode: Yes
Accepted in config mode: Yes
Accepted when Ready is low: No
Status of Ready signal during processing: Low
Supported interfaces:
Telegrams: Availability and supported
interfaces (Page 85)
06814859 - 1/24/2019-00 Page 190 EN
