Calibration: Set parameter (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Calibration: Set parameter (binary) request string to sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0x07 Telegram length
5
Unsigned
Char
0x29 Calibration: Set Parameter
6
Unsigned
Char
0x01 Request version
7
Unsigned
Char
0xXX
0: Temporary
1: Permanent
8
Unsigned
Char
0xXX Parameter number (Page 241)
9 - 12 Unsigned Int 0xXX Length of the following data
13 ... n
Unsigned
Char
0xXX Parameter value (Page 241)
Calibration: Set parameter (binary) response string from sensor
Byte no. Data type Content Meaning
1 - 4 Unsigned Int 0xXX Telegram length
5
Unsigned
Char
0x29 Calibration: Set Parameter
6 - 7
Unsigned
Short
0xXX Error codes (Page 88)
Additional information:
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is low: Yes
06814859 - 1/24/2019-00 Page 240 EN
