VISOR
®
Communications manual
<OPTIONAL FIELDS>
Parameter
Description
Length
ASCII
[Byte]
Data type
Available
for
Binary:
Bytes 1 and 2: Number of active
Outputs
Bytes 3 – n: Outputs,
bit-coded
Log.
Outputs
Returns the
logic gate
result for each
logic output.
1 ... 259
ASCII:
Starting from byte 1 Number of active
outputs (logic gate result assigned); 1 byte
per whole number place
Following bytes: One byte per logic output
P = Detector pass
F = Detector fail
0 = Inactive output (gap between two
active outputs)
Binary:
Byte 1 and byte 2: Number of active log.
Outputs
Byte 3 – n All active logic outputs,
All types
Execution
Returns the
1 ... 3 Signed integer All types
Page 175 EN 06814859 - 1/24/2019-00
