VISOR
®
Communications manual
<OPTIONAL FIELDS>
Parameter
Description
Length
ASCII
[Byte]
Data type
Available
for
incl.
the characters
for the
telegram
length itself.
place) = 12
Status byte
Represents
the trigger
mode.
3
ASCII:
PPF = Trigger; PFP = Free run
Binary:
0X06 0x00 = Trigger mode
0X05 0x00 = Free run mode
All types
Detector
results
Output of
overall result
for each
detector.
4 ... 261
ASCII:
Byte 1 = AND conjunction of all detectors
Byte 2 = Overall position tracking result
Byte 3 = Overall current job result
Followed by the number of detectors; one
byte per whole number place
Followed by one byte for each detector; P
= Detector pass
F = Detector fail
All types
Digital
outputs
Returns the
logic gate
result for each
digital output.
2 ... 7
ASCII:
Byte 1 Number of active outputs (logic
gate result assigned)
Followed by bytes 2 – 7; one byte per
output
P = Detector pass
F = Detector fail 0 = Inactive output (gap
between two active outputs)
All types
06814859 - 1/24/2019-00 Page 174 EN
