Calibration: Calibration plate (BINARY)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Calibration: Calibration plate (binary) request string to sensor
Byte no. Data type Content Meaning
1 - 4
Unsigned
Int
0x09 Telegram length
5
Unsigned
Char
0x24 Calibration: Calibrate by Plate
6
Unsigned
Char
0x01 Request version
7
Unsigned
Char
0xXX
0: Temporary
1: Permanent
8
Unsigned
Char
0xXX
0 - No fiducials are used. The origin of the
measurement coordinate system is
identical to the origin of the calibration
coordinate system.
1 - No fiducials are used. Measurement
coordinate system is identical to the device
coordinate system.
2 - Uses world system, fiducial job
3 - Uses world system, fiducials command
CAW
9
Unsigned
Char
0xXX
0: Calibration internal and external sensor
parameters
1: Validation of calibration
2: Calibration internal sensor parameters
5: Calibration transformation
measurement coordinate system
Calibration: Calibration plate (binary) response string from sensor
Byte no. Data type Content Meaning
1 - 4
Unsigned
Int
0x3D Telegram length
5
Unsigned
0x24 Calibration: Calibrate by Plate
