VISOR
®
Communications manual
Trigger (ASCII)
Telegrams: Availability and supported interfaces (Page 85)
Overview telegrams (Page 81)
Trigger (ASCII) request string to sensor
Byte no. Content Meaning
1 T
Trigger (simple trigger, in-
port)
2 R
3 G
Example: TRG
Trigger (ASCII) response string from sensor
Byte no. Content Meaning
1 T
Trigger (response to
command trigger without
index, via port 2006. If
defined: Result data
without index via port 2005)
2 R
3 G
4
P
F
P successful (Pass)
F Fail
Example: TRGP
Additional information:
Accepted in run mode: Yes
Accepted in config mode: Yes
Accepted when Ready is low: No
Status of Ready signal during processing: Low
Supported interfaces:
Telegrams: Availability and
supported interfaces (Page
85)
End of telegram: Max. 4 bytes (optional)
06814859 - 1/24/2019-00 Page 92 EN
