VISOR
®
Communications manual
0 - Failed image
8 - 11 X
Number of rows
e.g. 0480 / 0200
12 - 15 X
Number of columns
e.g. 0640 / 0320
16 - 19 X End of message string
20 ... n X Binary image data (rows * columns)
Example: GIMP0004800640...
Additional information:
Accepted in run
mode:
Yes
Accepted in config
mode:
No
Accepted when
Ready is low:
Yes
Status of Ready signal
during processing:
Low
Supported interfaces: Telegrams: Availability and supported interfaces (Page 85)
End of telegram: Max. 4 bytes (optional)
