VISOR
®
Communications manual
Accepted in run mode: Yes
Accepted in config mode: No
Accepted when Ready is
low:
Yes
Status of Ready signal
during processing:
Low
Supported interfaces: Telegrams: Availability and supported interfaces (Page 85)
*1) Byte No. 7: Command: Set reference string
Detector Function Command
Length of the following
data
Alignment Pattern matching
Threshold Min
Threshold Max
ResultOffsetPos_X
ResultOffsetPos_Y
ResultOffsetAngle
1
2
31
32
33
4
4
5
5
5
Alignment Contour
comparison
Threshold Min
Threshold Max
ResultOffsetPos_X
ResultOffsetPos_Y
ResultOffsetAngle
1
2
31
32
33
4
4
5
5
5
Alignment Edge detection
Transition probe 1
Transition probe 2
Transition probe 3
Score min probe 1
Score min probe 2
Score min probe 3
101
102
103
104
105
106
4
4
4
4
4
4
Pattern matching
Threshold Min
Threshold Max
ResultOffsetPos_X
ResultOffsetPos_Y
ResultOffsetAngle
1
2
31
32
33
4
4
5
5
5
Contour comparison Threshold Min 1 4
Page 209 EN 06814859 - 1/24/2019-00
