VISOR
®
Communications manual
Parameter name
Parameter
number
Parameter value Length Format
3: X rotation (in
degrees * 1000)
4: Y rotation (in
degrees * 1000)
5: X rotation (in
degrees * 1000)
Transformation calibration
coordinate system
012
0: X axis offset (in user
unit * 1000)
1: Y axis offset (in user
unit * 1000)
2: Z axis offset (in user
unit * 1000)
3: X rotation (in
degrees * 1000)
4: Y rotation (in
degrees * 1000)
5: X rotation (in
degrees * 1000)
8 bytes
per value
Signed
integer
Transformation
measurement coordinate
system
014
0: X axis offset (in user
unit * 1000)
1: Y axis offset (in user
unit * 1000)
2: Z axis offset (in user
unit * 1000)
3: X rotation (in
degrees * 1000)
4: Y rotation (in
degrees * 1000)
5: X rotation (in
degrees * 1000)
8 bytes
per value
Signed
integer
Z Offset 021 (in user unit * 1000) 8 Byte
Signed
integer
Focal length 022 (in mm *1000) 8 Byte
Signed
integer
Fiducial 1 024
in each case:
0: X value (user unit *
1000)
1: Y value (user unit *
1000)
2: Constant 0
8 bytes
per value
Signed
integer
Fiducial 2 025
Fiducial 3 026
Fiducial 4 027
06814859 - 1/24/2019-00 Page 244 EN
