VISOR
®
Communications manual
Value Description
Length
Binary
[Byte]
Data
type
Available
for
Delta pos.
Y
Y position delta between the taught object and
the found object,
1/1000 [user unit]
4
Signed
integer
Angle
Orientation of found object,
1/1000 [°]
4
Signed
integer
Angle
(45)
Orientation of bounding box for found code [°],
value range: -45° to 45°
4
Signed
integer
Angle
(180)
Orientation of object width (long axis) [°],
value range: -90° to 90°
0° = East, counterclockwise
4
Signed
integer
Angle
(360)
Orientation of object width (long axis) [°],
value range: -180° to 180°
0° = East, counterclockwise
4
Signed
integer
Delta
angle
Angle between taught object and found object,
1/1000 [°]
4
Signed
integer
Position
check
1 Boolean
