SENSTAR OmniTrax - Page 76

System drawings
Page 76 OmniTrax Product Guide
Figure 43: Sample site drawing (network system - details)
VIEW 'A'
gate
fence
sensor cables
sensor cables
long
terminators
EIA-422 communication
cables to NIU
SECTION A-A
15 cm (6 in.)
ground Level
23 cm (9 in.)
marker Tape
sensor cable
1.5 m
(4 ft., 11 in.)
air
soil
7.5 cm (3 in.)
Ethernet
cables
A-Side
B-side
EIA-422
cables
Processor #1
UltraWave
microwave receiver
Processor #4
VIEW 'B'
23 cm (9 in.) depth separation at sensor cable
crossover
4 m
(13 ft.)
VIEW 'C'
network decouplers
A-side sensor cables
LEGEND
SYMBOL
MEANING
OmniTrax PROCESSOR
SECURITY LIGHTING
NETWORK POWER SUPPLY
NETWORK INTERFACE UNIT
UCM & NM COMPUTER
MICROWAVE
DECOUPLER
TERMINATOR
OUTSIDE PERIMETER FENCE
PROCESSOR CABLE ID
SIZE
FSCM No.
PART NUMBER
DRAWING NUMBER
VAR.
52
SHEET
SCALE
Sample OmniTrax OC2 Site Plan
(4 Processors, 1 Microwave)
OF
Processor #
LTR
DESCRIPTION
CONFIGURATION BASELINE
DATE
APPD
Processor #1
ferrite beads
Zone 7
Zone 6
2.5 m (8 ft.)
8 m (26 ft.)
overlap
B-side sensor cables
7 m (23 ft.)
turn radius
2 m
(6.5 ft.)
3
0
c
m
(
1
2
i
n
.
)
ALARM REPORTING DETAILS
NIU
PC
2 m
60 cm
(2 ft.)
telecom style enclosure
60 cm
