Rear Components
Figure 3 shows the library’s rear panel components.
Note: Any bays that do not contain components must have covers
installed to maintain proper air circulation throughout the
library and to protect the internal components.
Figure 3 Library rear components (T380 with the 2N redundant power supply
option shown).
Drive Bay Assembly
Empty controller bay
Library Control
Module (LCM)
Flex bays (for DBAs
(DBA)
Tool storage
Chambers (3)
(cover removed)
or TBAs)
Empty drive bay
(behind cover,
(cover removed)
Drive
BlueScale Vision
camera connector
Optional controller
(RIM or QIP)
Power supply
modules (5/12 VDC)
T680 only)
Main AC power cord
connector and switch
(one on each side of
chassis)
and documentation
