1.2.6.3.2.2 Bootloader
Signals that are shown when the Bootloader is active:
Bootloader State No Fault
(firmware exists)
Fault
(no firmware exists)
Idle
Operation in progress
Note
If your servo drive is running Bootloader v1.0 you may find the LED fading in rainbow colors indicating
that the bootloader is active.
1.2.6.3.3 EtherCAT LED
Signals on the EtherCAT LED are required for EtherCAT conformity.
LED 1: Port 1 (In) ACT LED 2: Port 2 (Out) ACT LED 3: RUN
RUN is constantly showing a green light if there is a cable connected to either OUT or IN.
ACT is blinking when there are transmissions on either OUT or IN.
If none of the LEDs are active, check if the EtherCAT cables are connected properly.
