1.3.2.6.4.2 Truth table for digital inputs
Digital input STO-SBC 1 Digital input STO-SBC 2 Internal fault Safety Statusword Error
entry
0 0 no 1
0 1 no 1 “SfeDilvd
1 0 no 1 “SfeDilvd
1 1 no 0
0 0 yes 1 “SfeFault”
1.3.2.6.4.3 Diagnostic functions
1.3.2.6.4.3.1 Fault diagnostics
The safety circuit has two integrated diagnostic functions:
Comparing safety digital input statuses. The fault is activated after 100ms discrepancy of the STO-SBC
inputs. In case a fault is detected, the servo drive will enter Fault state and indicate a fault “SfeDilvd” in the
Error Report object.
During the activation of the STO-SBC function the servo drive verifies that the two channels of the module
are internally operating correctly. In case an internal fault is detected, the servo drive will enter Fault state
and indicate a fault “SfeFault” in the Error Report object.
1.3.2.6.4.3.2 Fault reaction
In case a fault has been detected, the drive will stay in fault state until manual reset has been given and the
brake is closed.
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 276/887
