3.1.9.1.57 0x2022 Position feedback filter
Measured position signal from the sensor can be filtered. There is only one type of filtering that the user can
choose:
1st order low pass filter with formula G(s)=1/(1+sT), where T=1/(2*pi*f),
The filter is implemented in discrete domain using Euler's forward difference discretization method, i.e. s=1/T*
(1-z^-1).
The filter is enabled by setting the filter type parameter to 1, and disabled by setting it to 0. Parameter cutoff
frequency is set in [Hz].
Name Index:Sub Type Bit
Size
Options Unit Access PDO
Mapping
Type 0x2022:1 USINT 8
Disabled 0
1st order low pass 1
readwrite
Name Index:Sub Type Bit
Size
Min
Data
Max
Data
Default
Data
Unit Access PDO
Mapping
Cutoff frequency 0x2022:2 UDINT 32 0 Hz readwrite
