Page #247 background image
1.3.2.4.1.3.5.1 EtherCAT IN Port
Pin Name Function
1 * TX+ Differential transmit pair, positive line
2 TX- Differential transmit pair, negative line
3 Shield
4 RX+ Differential receive pair, positive line
5 RX- Differential receive pair, negative line
* Pin 1 is on left
1.3.2.4.1.3.5.2 EtherCAT OUT Port
Pin Name Function
1 * TX+ Differential transmit pair, positive line
2 TX- Differential transmit pair, negative line
3 Shield
4 RX+ Differential receive pair, positive line
5 RX- Differential receive pair, negative line
* Pin 1 is on left
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 247/887
