IMPORTANT

AnoriceisplacedbeneaththepluginthecontrolmanifoldOR2,

OR4,OR6andOR8ports.Iftheplugsareremoved,makesureto

removetheorice,noteitsorientationandlabelitspositionfor

assemblypurposes.

Note:Theliftcontrolmanifoldincludesseveralzero−leakplugs.Theseplugs

haveataperedsealingsurfaceontheplugheadthatisdesignedtoresist

vibrationinducedplugloosening.Thezero−leakplugsalsohaveanO−ring

asasecondaryseal.Ifzero−leakplugremovalisnecessary,lightlyrapthe

plugheadusingapunchandhammerbeforeusinganallenwrenchtoremove

theplug:theimpactwillallowplugremovalwithlesschanceofdamagetothe

socketheadoftheplug.Wheninstallingplugs,refertomanifoldillustrationfor

pluginstallationtorque.

CartridgeValveService

Forcartridgevalveserviceprocedures,seeCartridgeValveService(page

5–158).

Groundsmaster

5900&5910

Page5–157

HydraulicSystem:ServiceandRepairs

16227SLRevB
