CartridgeValveService(continued)

IMPORTANT

Usecarewhenhandlingthevalvecartridge.Slightbendingor

distortionofthestemtubecancausebindingandmalfunction.

B.Fitcartridgevalvecarefullyintomanifoldport.Thevalveshouldgoin

easilywithoutbinding.

C.Tightenthecartridgevalveusingadeepsocket(valvesthatthread

directlyintothemanifoldblock)oranextendedhexwrenchsocket(ange

mountedcartridgevalves)tothevalueidentiedinmanifoldservice

illustration.

D.Ifcartridgeusesareplaceablesolenoidcoil,carefullyinstallsolenoid

coiltothecartridgevalve.Tightencoilnuttovalueidentiedinmanifold

serviceillustration.Over−tighteningmaydamagethesolenoidorcause

thevalvetomalfunction.

8.Ifproblemsstillexist,removevalveandcleanagainorreplacevalve.

Groundsmaster

5900&5910

Page5–159

HydraulicSystem:ServiceandRepairs

16227SLRevB
