Toro Groundsmaster 5910 Series User Manual

HydraulicOilCooler
1
2
2
3
3
4
4
5
5
6
6
7
8
8
9
g288226
Figure134
1.Coolingfanassembly4.Capscrew(4)7.OilCooler
2.Capscrew(4)5.Flatwasher(4)8.Hydraulicstraighttting(2)
3.Flatwasher(4)6.IsolatorMount(4)9.Flangenut(4)
HydraulicOilCoolerRemoval(Figure133)
CAUTION
Theoilcoolermaybehot.Toavoidpossibleburns,allowtheengine
andhydraulicsystemstocoolbeforeworkingontheoilcooler.
1.Parkmachineonalevelsurface,lowercuttingdecksfully,disengagePTO
andstopengine.Removekeyfromthekeyswitch.
2.Raisehoodtogainaccesstooilcooler.
3.ReadtheGeneralPrecautionsforRemovingandInstallingHydraulicSystem
Components(page5–73).
HydraulicSystem:ServiceandRepairs
Page5–160
Groundsmaster
®
5900&5910
16227SLRevB
