REGENERATION(continued)

g288314

Figure150

1.Button14.Button4

2.Button25.Button5

3.Button3

Parkthemachineonahardlevelsurfaceinawellventilatedareawhereitcan

remainuntiltheprocessiscomplete.Makesurethemachinehasanadequate

supplyoffuelbeforebeginningtheautomatedregenerationprocess.When

ready,accesstheregenerationscreenandpressbutton4(Figure150).During

theregenerationprocess,theInfoCenterdisplaywillidentifythepercentofthe

processcompleted.

Returntothepreviousscreenbypressingbutton5.

Groundsmaster

5900&5910

Page6–21
