Testing(continued)

g288457

Figure204

BackofSwitch

3.TheswitchterminalsaremarkedasshowninFigure204.Thecircuitlogic

ofthebattery−disconnectswitchisshowninbelowtable.Withtheuseofa

multimeter(ohmssetting),theswitchfunctionsmaybetestedtodetermine

whethercontinuityexistsbetweenthevariousterminalsforeachswitch

position.Verifycontinuitybetweenswitchterminals.

SWITCHPOSITIONCLOSEDCIRCUITSOPENCIRCUITS

OFFNONE

1+2and3+4

NONE

4.Replacetheswitchiftestingdeterminesthatitisfaulty.

5.Iftheswitchtestscorrectlyandacircuitproblemstillexists,checkthewire

harnesses(seeAppendixA(pageA–1)).

6.Turnthebattery−disconnectswitchtotheONpositionbeforereturningthe

machinetoservice.

ElectricalSystem:ComponentTesting

Page6–62

Groundsmaster

5900&5910

16227SLRevB
