Toro Groundsmaster 5910 Series User Manual

HighFlowHydraulicFilterKit
K-LinePartNumber:TOR6011
Thehighowhydrauliclterkitisdesignedwithlargeow(150
LPMor40GPM)andhighpressure(34,500kPaor5,000psi)
capabilities.Thiskitprovidesforbidirectionalltrationwhich
preventslteredunwantedmaterialfromenteringintothecircuit
regardlessoftheowdirection.
Ifacomponentfailureoccursintheclosed-looptractioncircuit,
contaminationfromthedamagedpartwillremaininthecircuit
untilyouremoveit.Installahighowhydraulic-uidlterintothe
circuitwhenyouconnectthehydraulictestgaugesinorderto
testthetractioncircuitcomponentsorafteryoureplaceafailed
tractioncircuitcomponent(e.g.,pistonpumporwheelmotor).This
lterremovescontaminationfromthehydraulicuidinthetraction
circuit,therebypreventingadditionalcomponentdamage.
Note:Thiskitdoesnotincludethehydraulichoses;referto
HydraulicHoseKit(page2–16).
Note:ThereplacementlterelementisT oroPartNo.TOR6012.
Thelterelementcanistertighteningtorqueis34N∙m(25ft-lb).
MeasuringContainer
K-LinePartNumber:TOR4077
Usethiscontainertotesthydraulicmotorefciency(motors
withcasedrainlinesonly).Limittheoutletowfromthemotor
andmeasuretheleakagefromthecasedrainlinetomeasure
theefciencyofahydraulicmotorwhilethehydraulicsystem
pressurizesthemotor.
Thetablegivesthegallonsperminute(gpm)conversionforthe
measuredmilliliterorouncemotorcasedrainleakage.
GPMmL/15secondsoz/15seconds
0.1953.2
0.21896.4
0.32849.6
0.437812.8
0.547316.0
0.656819.2
0.766222.4
0.875625.6
0.985228.8
1.094632.0
SpecicationsandMaintenance:SpecialTools
Page2–18
Groundsmaster
®
5900&5910
16227SLRevB
