DielectricGel

ToroPartNo.107-0342

Usethedielectricgeltoprevent

corrosionofunsealedconnection

terminals.T oensurecomplete

coatingoftheterminals,liberally

applythegeltothecomponent

andwireharnessconnector,plug

theconnectorintothecomponent,

unplugtheconnector,applythegel

tobothsurfacesagain,andconnect

theharnessconnectortothe

componentagain.Theconnectors

mustbefullypackedwithgelfor

effectiveresults.

Note:Donotusethedielectricgel

onthesealedconnectionterminals

asthegelcanunseattheconnector

sealsduringassembly.

BatteryHydrometer

Usethebatteryhydrometerwhen

measuringthespecicgravityofthe

batteryelectrolyte.Youcangetthistool

locally.

SpecicationsandMaintenance:SpecialTools

Page2–20

Groundsmaster

5900&5910

16227SLRevB
