FuelLines,FiltersandFuelPumpRemoval
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
5
5
5
5
5
5
5
6
7
8
9
10
21
22
23
24
25
SUPPLY
VENT
RETURN
g287553
Figure21
1.Fuelhose−supplyfromtank10.Flangeheadscrew(2)
19.Fuelhose−returntotank
2.Fuel/waterseparatorelement
11.Fuelpump
20.Rivet(2)
3.Fuel/waterseparatorhead12.Grommet21.Clip(2)
4.Straightbarbtting13.Fuelhose−ltertoinjectionpump22.Venttube(attachedtoR.O.P .S.)
5.Hoseclamp(11)14.Fuelhose−Yjunctiontolter23.Fuelhose−ventfromtank
6.Flangenut(2)15.Flangenut(2)24.Clamp
7.Flangeheadscrew(2)
16.Fuellterhead
25.Flangeheadscrew
8.Straightbarbtting17.Fuellterelement
9.Fuelhose−fuel/waterseparatorto
pump
18.Flangeheadscrew(2)
1.Parkmachineonalevelsurface,lowercuttingdecks,stopengineand
removekeyfromthekeyswitch.
2.Raisethehoodandremovesidepanelfromleftsideofmachinetogain
accesstofuellines,ltersandfuelpump.Allowengineandexhausttocool
beforedoinganydisassemblyoffuelsystemcomponents.
3.Labelfuelhosestoassureproperassembly(Figure21).
YanmarDieselEngine:ServiceandRepairs
Page4–20
Groundsmaster
®
5900&5910
16227SLRevB
