7.5 Enabling Local Authentication
224
3.
On the menu screen, press
[Tools].
Note
Pr
ess the <Services Home> button on the
control panel to d
isplay the menu scr
een, if not
yet
di
sp
la
yed
.
4.
Press [Authentication / Security Settings] >
[Authentication] > [Login Type].
5.
Press [Login to Local Accounts].
Refer
F
or more inf
ormati
on, ref
er to "Login T
ype" (p.
332).
6.
Press [Save].
223
225
