Xerox WorkCentre 5020 Service Documentation

July, 2007
6-6
WorkCentre 5020
Initial Issue
General Procedures
Output Diagnostics
The Output Diagnostics can be used to operate and check the status of the various motors,
solenoids and clutches in the engine, IIT, and Trays. The operation can be enabled for every
component, and whether or not the component is operating properly can be determined by
checking the operation from outside.
When a component is operating, "run" is displayed.
Pressing the [Stop] button will stop the operation of the component and return you to the Func-
tion Code input screen.
To resume the operation of the specified component, press the [Start] button again.
09 07 XERO Toner Empty Sensor L: Toner available
H: Toner depleted
10 23 PH Fuser Exit Sensor L: No paper
H: Paper present
10 60 FUSER Nohad Fan Fail Monitor L: Able to monitor FUSER
FAN FAIL
H: Unable to monitor
FUSER FAN FAIL
Chain Func Sub Contents of Data Meaning
04 01 PH IOT Motor ON
04 02 FUSER Nohad Fan Motor
(HIGH SPEED)
Fuser Fan changes from
Low to High speed
Chain Func Sub Contents of Data Meaning
r
r u n
F
F 2 3
05 20 IIT Carriage Motor High
Speed scan
Move the Carriage in the
scan direction at 80mm/
sec. NOTE: After the
scan, the Carriage stops
beyond the end position.
Pressing the [Start] but-
ton again returns the Car-
riage to the home
position. After another
scan, the Carriage stops
beyond the end position.
Turn the power off and on
to return the Carriage to
the home position.
05 21 IIT Carriage Motor High
Speed return
Move the Carriage
toward home position at
80mm/sec. NOTE: See
05-20.
05 22 IIT Carriage Motor Low
Speed scan
Move the Carriage in the
scan direction at 40mm/
sec. NOTE: See 05-20.
05 23 IIT Carriage Motor Low
Speed return
Move the Carriage
toward home position at
40mm/sec. NOTE: See
05-20.
06 15 ROS ROS Motor ON ROS Motor Start & Stop
08 10 PH IOT Registration
Clutch
08 11 TRAY STM Feed Clutch
08 12 TRAY Tray1 Feed Clutch
08 13 TRAY STM Feed Motor
08 17 PH Bypass Solenoid
09 04 XERO HVPS ON (LOW
VOLTAGE)
Chain Func Sub Contents of Data Meaning

Xerox WorkCentre 5020 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Print Resolution	Up to 600 x 600 dpi
Max Paper Size	A3
Standard Paper Capacity	250 sheets
Bypass Tray Capacity	100 sheets
Duplex Printing	Manual
Copy Speed	Up to 20 cpm
First Page Out Time (Copying)	Less than 10 seconds
Scan Resolution	Up to 600 x 600 dpi
Operating System Compatibility	Windows, Mac OS
Automatic Document Feeder	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy
Reduction / Enlargement	25% - 400%
Scan Destinations	USB, Email
Fax Transmission Speed	33.6 kbps
First Page Out Time (Printing)	Less than 8 seconds
