Xerox WorkCentre 5020 Service Documentation

July, 2007
6-8
WorkCentre 5020
Initial Issue
General Procedures
Display Error History [40-01]
This can be used to check for the last 20 errors.
Pressing the [Start] button will display the error codes, starting with the most recent error.
When the last error is displayed, press the [Start] key to return to the Function Code input
screen.
Pressing the [Stop] key during the display will stop it and return you to the Function Code input
screen.
Check Print Count [25-01]
This can be used to check the total print count. The display is in decimal numbers.
The initial display shows the first 3 digits of the print count. Pressing the [Start] button will show
you the next 3 digits.
Pressing the [Start] button again will return you to the Function Code input screen.
Display Firmware Version [29-49]
This can be used to check the firmware versions of the Controller and the MCU.
Pressing the [Start] button will display the firmware version, starting from the highest order (left-
most) digit.
Once everything has been displayed, you will be returned to the Function Code input screen.
Clear Error History [20-59]
This can be used to clear the Error History.
While the Error History is being cleared, "run" is displayed.
Once the Error History has been cleared, you will be returned to the Function Code input
screen.
Display Serial Number [25-20]
This can be used to display the serial number of the machine.
Pressing the [Start] button will display the serial number, starting from the highest order (left-
most) digit.
Once the whole serial number has been displayed, you will be returned to the Function Code
input screen.
J
J 6 1
E
E 1 6
J
J 1 6
F
F _
1
1
7
7 1 6
F
F 1
1
1
2
2
a
a
F
F 1
r
r u n
1
1
2
2 3 4
5
5 6 7
8
8 9 0
F
F 1

Xerox WorkCentre 5020 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Print Resolution	Up to 600 x 600 dpi
Max Paper Size	A3
Standard Paper Capacity	250 sheets
Bypass Tray Capacity	100 sheets
Duplex Printing	Manual
Copy Speed	Up to 20 cpm
First Page Out Time (Copying)	Less than 10 seconds
Scan Resolution	Up to 600 x 600 dpi
Operating System Compatibility	Windows, Mac OS
Automatic Document Feeder	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy
Reduction / Enlargement	25% - 400%
Scan Destinations	USB, Email
Fax Transmission Speed	33.6 kbps
First Page Out Time (Printing)	Less than 8 seconds
