Xerox WorkCentre 5020 Service Documentation

July, 2007
6-13
WorkCentre 5020
General Procedures
Initial Issue
07 47 TRAY Tray2-paper size 0~254 1mm 2 O O O value paper type
1: 11”x17” SEF
2: A3 SEF
3: 8K SEF*1
5: B4SEF
6: 8.5”x14” SEF(Legal)
7: 8.5”x13.4” SEF(Mexico Folio)
8: 8.5”x13” (Folio)
10: A4 SEF
11: 8.5”x11” SEF(Letter)
12: 16K SEF*1
15: B5 SEF
17: 8.5”x11” LEF(Letter)
07 48 TRAY MSI Paper size 0~254 1mm 2 O O O value paper type
1: 11”x17” SEF
2: A3 SEF
3: 8K SEF*1
5: B4SEF
6: 8.5”x14” SEF(Legal)
7: 8.5”x13.4” SEF(Mexico Folio)
8: 8.5”x13” (Folio)
10: A4 SEF
11: 8.5”x11” SEF(Letter)
12: 16K SEF*1
15: B5 SEF
17: 8.5”x11” LEF(Letter)
18: 5.5”x8.5” S
19: A5 S
20 01 PH LEAD REGI ADJUSTMENT
- ALL TRAY
0~60 0.146
mm
30 O O O Image input is delayed when Set Value is
increased.
Min(0)=-4.46mm, Max(66)=4.46mm,
Initial(33)=0mm
20 41 PH TRAY1 for Normal LEAD
REGI ADJ
0~60 0.146
mm
30 O O O Image input is delayed when Set Value is
increased.
20 42 PH TRAY2 for Normal LEAD
REGI ADJ
0~60 0.146
mm
30 O O O Image input is delayed when Set Value is
increased.
Chain
Func
tion Sub Contents of Data Range Unit
Initial
Value
CE
Access
RemarksRWInit

Xerox WorkCentre 5020 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Print Resolution	Up to 600 x 600 dpi
Max Paper Size	A3
Standard Paper Capacity	250 sheets
Bypass Tray Capacity	100 sheets
Duplex Printing	Manual
Copy Speed	Up to 20 cpm
First Page Out Time (Copying)	Less than 10 seconds
Scan Resolution	Up to 600 x 600 dpi
Operating System Compatibility	Windows, Mac OS
Automatic Document Feeder	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy
Reduction / Enlargement	25% - 400%
Scan Destinations	USB, Email
Fax Transmission Speed	33.6 kbps
First Page Out Time (Printing)	Less than 8 seconds
