July, 2007
6-14
WorkCentre 5020
Initial Issue
General Procedures
20 43 PH SMH for Normal LEAD REGI
ADJ
0~60 0.146
mm
30 O O O Image input is delayed when Set Value is
increased.
20 45 PH DUP ALL SIZE for Normal
LEAD REGI ADJ
0~60 0.146
mm
30 O O O Image input is delayed when Set Value is
increased.
20 46 PH ALL TRAY - REGI LOOP
TIMER
0~66 0.438
mm
33 O O O Loop increases when Set Value is
increased.
20 47 PH TRAY1 for Normal Paper -
REGI LOOP TIMER
0~66 0.438
mm
33 O O O Loop increases when Set Value is
increased.
20 48 PH TRAY2 for Normal Paper -
REGI LOOP TIMER
0~66 0.438
mm
33 O O O Loop increases when Set Value is
increased.
20 49 PH SMH for Normal Paper - REGI
LOOP TIMER
0~66 0.438
mm
11 O O O Loop increases when Set Value is
increased.
20 51 PH DUP for Normal Paper - REGI
LOOP TIMER
0~66 0.438
mm
33 O O O Loop increases when Set Value is
increased.
21 09 HFSI Last 2 of Fuser discharging
Number
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
21 19 HFSI 5th & 6th Fuser discharging
Number
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
21 29 HFSI 3rd & 4th Fuser discharging
Number
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
21 39 HFSI 1st 2 of Fuser discharging
Number
0~3 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
23 20 PH Simplex/Duplex 0~1 1 O O O 0: Simplex
1: Duplex
Chain
Func
tion Sub Contents of Data Range Unit
Initial
Value
CE
Access
RemarksRWInit
To Next Page
