Xerox WorkCentre 5020 Service Documentation

July, 2007
6-17
WorkCentre 5020
General Procedures
Initial Issue
30 34 Recycle 1st 2 Digits of MSI Feed
Capacity (8 Digits)
0~3 1 0 OXX
30 05 Recycle Last 2 of IOT Starting Number 0~99 1 0 O X X
30 15 Recycle 3rd & 4th IOT Starting
Number
0~99 1 0 O X X
30 25 Recycle 1st 2 of IOT Starting Number 0~99 1 0 O X X
30 06 Recycle Tray1 Last 2 Digits of Feed
Capacity (8 Digits)
0~99 1 0 O X X
30 16 Recycle Tray1 5th & 6th Digits of Feed
Capacity (8 Digits)
0~99 1 0 O X X
30 26 Recycle Tray1 3rd & 4th Digits of
Feed Capacity (8 Digits)
0~99 1 0 O X X
30 36 Recycle Tray1 1st 2 Digits of Feed
Capacity (8 Digits)
0~3 1 0 OXX
30 07 Recycle Tray2 Last 2 Digits of Feed
Capacity (6 Digits)
0~99 1 0 O X X
30 17 Recycle Tray2 5th & 6th Digits of Feed
Capacity (6 Digits)
0~99 1 0 O X X
30 27 Recycle Tray2 3rd & 4th Digits of
Feed Capacity (6 Digits)
0~99 1 0 O X X
30 37 Recycle Tray2 1st 2 Digits of Feed
Capacity (8 Digits)
0~3 1 0 OXX
30 41 HFSI Last 2 Digits of the number of
Sheets Reaching BIAS transfer
Roll (8 Digits)
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
30 42 HFSI 5th & 6th Digits of the number
of Sheets Reaching BIAS
transfer Roll (8 Digits)
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
Chain
Func
tion Sub Contents of Data Range Unit
Initial
Value
CE
Access
RemarksRWInit
