July, 2007
6-16
WorkCentre 5020
Initial Issue
General Procedures
29 05 HFSI Tray2 Last 2 Digits of Feed
Capacity (6 Digits)
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
29 15 HFSI Tray2 5th & 6th Digits of Feed
Capacity (6 Digits)
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
29 25 HFSI Tray2 3rd & 4th Digits of
Feed Capacity (6 Digits)
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
29 09 HFSI MSI Last 2 Digits of Feed
Capacity (8 Digits)
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
29 19 HFSI MSI 5th & 6th Digits of Feed
Capacity (8 Digits)
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
29 29 HFSI MSI 3rd & 4th Digits of Feed
Capacity (8 Digits)
0~99 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
29 39 HFSI MSI 1st 2 Digits of Feed
Capacity (8 Digits)
0~3 1 0 O O X Only 0 clearance is possible in the write
mode.
("0 clearance" means all bytes change to 0
at the same time.)
30 04 Recycle Last 2 Digits of MSI Feed
Capacity (8 Digits)
0~99 1 0 O X X
30 14 Recycle 5th & 6th Digits of MSI Feed
Capacity (8 Digits)
0~99 1 0 O X X
30 24 Recycle 3rd & 4th Digits of MSI Feed
Capacity (8 Digits)
0~99 1 0 O X X
Chain
Func
tion Sub Contents of Data Range Unit
Initial
Value
CE
Access
RemarksRWInit
